Standard Product Features
- Network size: 64 controlled devices
- Outdoor reset
- 3 reset slopes - 2 summer, 1 winter
- Condensing and non-condensing priority set-point
- Optimum stop setback, optimum start boost
- Post-cycle pump purge based on run time percent with max limit (boost to 100%)
- Acceleration boiler, boiler pump, and system pump modulation outputs
- Sequential/parallel/optimized modulation
- Low fire hold with respect to load and occupied space temperatures
- DHW priority, DHW supply set-point, DHW priority override
- Event scheduling for occupancy used for start and stop
- External system enable contact, external system reset analog input
- Calculates real-time load, displays real-time load calculation, and modulates based on real-time load (not supply temperature)
- Knows boiler max and min BTU outputs and selects/utilizes accordingly
- Intelligent load selection - chooses boilers based on their relationship to the load for operation
- Intelligent shutdown uses load, size, type, priority, hours of operation for shutdown of boilers
- Chooses boilers based on priority for condensing or non-condensing
(hybrid)
- Intelligent load sharing
- Measures supply return and system flow to determine real-time load
- Condensing protection program insures non-condensing boilers see minimum water temperatures > 130°F
- System pump rotation lead/lag
- 7" LCD full-color touchscreen Graphical User Interface
- Real English language on screen prompts
- 3-way valve control
- All points alarm
- User selectable modulation signals 0-10Vdc, 4-20mA
- Minimum modulation signal during run cycle
- Internal load predictions based on outdoor air, redundancy factor and history
- Embedded Windows page for PC interaction - hardwired or wireless
- USB port for graphical and code-based updates
- Wireless network configuration with 128-bit signal encryption
- Hardwire network backup
- Uses boiler manufacturer's unique product data in Acceleration Control Algorithm for modulation tuning
- Minimum stage delay at any percentage of boiler output
- Standard Equipment: 1 system administrator, 1-64 field devices,
1 flow meter with hot tap, 2 thermistors with wells, 1 outdoor
air thermistor with shield
Simplicity - Easy to Set Up, Easy to Use
Install a mechanical room control for about a 95% reduction in materials and 85% reduction in labor with the SoloNet wireless platform.
With 128-bit encryption and 16 self-selecting channels, interference and dropped communication are virtually eliminated, so information shared on the network is both safe and secure. And LiveFire Connect™ communication hardware assures unrivaled strength of signal.
Simply supply power and communication begins. From there, follow the on-screen prompts and your entire setup will be done in mere minutes. Clean, simple, hassle-free!
Equipment Selection guide - Maximum 64 controlled devices (48 modulating)
- 1 - 16 Boilers
- 1 - 16 Boiler Pumps
- 1 - 16 System Pumps
- 1 - 16 Dampers
- 1 - 16 Combustion air make-up/exhaust devices
- 1 - 16 Automatic isolation valves
